KEWPAT Pro - For use with Kewtech KT74, KT75 and KT77 as well as Robin SmartPat 5000, 5500 and including support for the manual entry of test data.

KEWPAT Pro is the Kewtech Corp branded version of SimplyPats. This version only supports download and/or import of data from the Kewtech KT74, KT75, KT77, Robin SmartPat 5000/5500 with manual (non downloading) PAT Testers being supported through the Manual Entry Screen.

Your KEWPAT Pro software may be refered to as SimplyPats in the Help File and on our Web Site. This is to ensure that KEWPAT Pro users can take advantage of all future developements in SimplyPats. This also means that we only need to support one product.

All support for your KEWPAT Pro software is handled through RSR Systems Ltd, using the normal methods; Phone (UK Local Rate), Email or Forum, please see our web site for further information.

Limitations of the KEWPAT Version compared to the native version of SimplyPats Version 6 are as follows;

• The only downloadable PAT Tester supported are those mentioned above.
• Import of other PAT manufacturers data files has been removed.

Licencing your KEWPAT Pro software.

You must first licence your software before the download from your PAT Tester or the manual entry features become available. You can licence your software by clicking here and following the links to Licence Your Software. Alternitively, from KEWPAT Pro, click "Help" on the file menu and choose "Licence SimplyPats", where you will find a direct link to the licence page. See Also Licencing SimplyPats

You will need the following information at hand:

• The Serial Number (This can be found on the inside of the CD Box, on a card or in the email we sent you if the software was dilivered digitally)
• Your Company or Trading Name.
• The Name of the person you wish to register the software to.
• Telephone Number and Full address and email address if you have one.

Updating your KEWPAT Pro software.

KEWPAT Pro users can take advantage of the same FREE updates, utilities and custom reports that are offered for download to SimplyPats users. Please note, that certain features contained in these free downloads may not apply due to the limitations of the KEWPAT Pro software, please see above.

All updates and other files are available from the SimplyPats Web Site or Forum.

Downloading Data from the supported PAT Testers.

Kewtech KT77
Kewtech KT74/KT75
Robin 5000/5500

Support for Manual PAT Testers.

For details regarding manually entering test and asset information, please refer to the manual entry section.

Download Cable and USB Adaptor

Serial Download Cable - Please be aware that some PAT Tester Serial Cables have specific wiring arrangements, please see wiring the download cable for more information

USB Memory Stick - If your PAT Tester supports the use of a USB Memory stick, these may be specific, please check with your manufacturer before purchasing a 3rd party device.

USB to Serial Converters - These are also specific, if in doubt please contact SimplyPats support for further information.

Related Information

Please make sure you have read the manual supplied with your PAT prior to using your tester.
Before testing in the field please make sure you have read, and fully understand the following topics, which can be found in the Online help. It`s a good idea to practice testing and using your software at home or around the office before going out on a job.

Before testing with your PAT
Setting up SimplyPats
Setting up your Company information
Setting up the Settings for Downloading
Setting up Your PAT

Return To Contents

(Last Updated 06/10/2011)
